Posiflex CD-3200 2D Imager Scanner USB Black, no stand
CD-3200 2D Imager Scanner USB Black, no stand
CMOS array sensor
2 x Visible Red LED
Resolution: 752 (H) x 480 (V) pixels
Up to 60 f/sec
Product overview
CD-3200 2D Imager Scanner USB Black, no stand
Features:
- Handy 2D image scanner
- Light source: 2 x red LED
- Scan Method: CMOS array sensor
- Resolution: 752 (H) x 480 (V) pixels
- Depth of Field: 40~120 mm (15 mils QR code)
- Scan Angle: Horizontal – 41°, Vertical – 26°
- Scan Rate: Up to 60 fps
- Scans most common 1D, 2D and Postal Codes
- USB or Serial Interface
Key details
- Brand
- Posiflex
- SKU
- CD-3200U-B
- Category
- Barcode Scanner
- Scan Engine
- CMOS array sensor
- Light Source
- 2 x Visible Red LED
- Scan Pattern
- Resolution: 752 (H) x 480 (V) pixels
- Scan Rate
- Up to 60 f/sec
- Resolution
- Typical 5mils
- Depth of field
- 40~120 mm (15 mils QR code)
- Symbologies supported
- 1D Barcode Support: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBNISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
2D Barcode Support: Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417
Postal Code Support: Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code - Programming Method
- Bar code command
- Indicators/Controls
- LED indication, Programmable Beeper
- Communication Type
- Corded
- Interfaces
- USB HID, USB Virtual COM, RS232
- Drop Specification
- Withstands multiple drops from 1.5m onto concrete
Features
- Scan Engine: CMOS array sensor
- Light Source: 2 x Visible Red LED
- Scan Pattern: Resolution: 752 (H) x 480 (V) pixels
- Scan Rate: Up to 60 f/sec
- Resolution: Typical 5mils
- Depth of field: 40~120 mm (15 mils QR code)
- Symbologies supported: 1D Barcode Support: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBNISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
2D Barcode Support: Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417
Postal Code Support: Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code - Programming Method: Bar code command
- Indicators/Controls: LED indication, Programmable Beeper
- Communication Type: Corded
- Interfaces: USB HID, USB Virtual COM, RS232
- Drop Specification: Withstands multiple drops from 1.5m onto concrete
System requirements
- Brand
- Posiflex
- SKU
- CD-3200U-B
- Category
- Barcode Scanner
- Scan Engine
- CMOS array sensor
- Light Source
- 2 x Visible Red LED
- Scan Pattern
- Resolution: 752 (H) x 480 (V) pixels
- Scan Rate
- Up to 60 f/sec
- Resolution
- Typical 5mils
- Depth of field
- 40~120 mm (15 mils QR code)
- Symbologies supported
- 1D Barcode Support: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBNISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
2D Barcode Support: Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417
Postal Code Support: Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code - Programming Method
- Bar code command
- Indicators/Controls
- LED indication, Programmable Beeper
- Communication Type
- Corded
- Interfaces
- USB HID, USB Virtual COM, RS232
- Drop Specification
- Withstands multiple drops from 1.5m onto concrete
